Welcome to AKCP Solutions
The Worlds Oldest and Largest Manufacturer of SNMP Enabled Wired and Wireless Sensors
The sensorProbe2+ LCD (SP2+LCD) is based on our popular SP2+ device. Equipped with 4 sensor ports, a dry contact I/O it is ideal for server rooms and monitring of individual racks. Connect any AKCP intelligent sensor such as thermal maps, sensor status light, contactless current meters and water leak detection. Mounted on the front, or with a 45° bracket on the top of your rack, the LCD vides a visual display of all sensor status and values.
About Us
Advanced Alarm is main distributor of AKCP products, where AKCP is the worlds leader in remote monitoring solutions. Our Wireless Tunnelâ„¢ radio sensor technology gives superior range and excellent penetration within buildings and through obstructions.
Corporate Overview, About AKCP
Power Monitoring with Billing Grade Accuracy
powerProbeX+
Monitor up to 48 individual circuits, 1 phase or 3 phase
The powerProbe+ is part of the sensorProbe+ product family. A standalone unit with its own IP address it connects with up to 48 individual circuits. Installed at breaker panels with CT’s for each circuit and up to 3x voltage inputs for monitoring 1ph or 3ph power. No high voltage or current enters the unit, as voltage transformers and CT’s are utilized to isolate the device from the mains power. Ideal for colocation data centers who need to monitor with billing grade accuracy individual racks. It is a cost effective way to monitor power to many circuits within your facility.
A Modbus RS485 port is included to interface with third party devices, and a Basic Expansion Bus (BEB) port allows expansion with additional sensor ports, dry contacts and mini relays.
AKCP Product Platforms
Customizable and expandable Wireless Tunnel Sensor Gateway
The WTS collects data from up to 30 AKCP Wireless Tunnelâ„¢ Sensors. View data via the embedded Web UI or consolidate data from multiple gateways on AKCPro Server
WiFi
If the WTS is placed in an area you don’t have accessible Ethernet cable for network connection, use the WiFi option to connect with your IP network. WiFi can also function as a hotspot for direct access without a wired or wireless network
Cellular
For sites that have no internet connection avaialble, the cellular data modem will transmit all your sensor data over the cellular network. In standalone installations, the cellular modem can also be used for sending SMS alerts. With the internal batteries the WTS will remained powered long enough to alert of power outages via SMS
GPS
Geolocate your WTS and monitoring locations on AKCPro Server world map. Geofence the device and know when it has moved out of a defined area.
Modbus RS485
Connect your WTS to 3rd party Modbus devices for monitoring generators and other industrial equipment.
Wireless Temperature and Humidity
Connect up to 30 SP-WT devices to the sensorProbe+ Wireless Tunnelâ„¢ Server (SP-WTS), with 4 sensors on each that gives 120 sensors from only 30 radios. The SP-WT is powered by either 3x AAA batteries, or 5VDC USB input. Both can be used with the batteries as a failover power source. It is recommended where possible to power the SP-WT via USB power supply.
Warehouse Temperature Monitoring
Wireless Tunnelâ„¢ sensors have a long range and low power for battery life of up to 10 years. Distribute sensors around your warehouse and on racking. Sensor data is logged and broadcast at regular intervals to the nearest Wireless Tunnel Sensor Gateway or Wireless Tunnel Repeater.
DCIM AKCPro Server
AKCPro Server is our central monitoring and management software. Monitor
your infrastructure, whether it be a single building, or remote sites over a wide
geographic area. Integrate third party devices with, Modbus. Support for ONVIF
compatible IP cameras
AKCP Platforms
SensorProbe SP2+
SensorProbe SPX
securityProbe
SensorProbe SP2+LCD
sensorProbe2+ (SP2+)
The world’s best selling environmental monitoring platform has been upgraded. Start with a basic package to enable monitoring over a single cabinet. Expand to a full data center monitoring solution, one cabinet at a time. Every computer rack monitored using AKCPro Server. sensorProbe2+ with Modbus RS485 port the sensorProbe2+ becomes a Modbus to SNMP gateway.
IP based, including SNMPv3, HTTPS, VPN
Send encrypted SNMP Trap and Email Notifications
Supports 4 Intelligent Sensors or up to 20 Dry Contacts
Optional cellular modem with external antenna
Optional Expansion Module connectivity
Virtual Sensors
Optional Modbus / Canbus
sensorProbeX+
The latest generation of sensorProbe devices, in a form factor that allows for 1U, 0U and DIN rail mounting. A low profile design that is economical on cabinet space. sensorProbeX+ comes in several standard configurations, or can be customized by choosing from a variety of modules such as dry contact inputs, IO’s, internal modem, analog to digital convertors, internal UPS and additional sensor ports.
Every sensorProbeX+ is equipped with Ethernet, Modbus RS485, EXP and BEB communications
Compatible with sensorProbeX+ EXP and BEB units, expand the capabilities of your device.
1U rackmount brackets, Tool-less 0U mounting or DIN rail mounting options.
Notification by SNMP, Email, SMS (requires optional cellular modem), built in buzzer.
Compatible with wide range of AKCP Intelligent sensors.
Start with base configuration and build up your device with modules you need.
Up to 80 virtual sensors.
securityProbe 5ES-X20
Monitor the physical environment and receive alerts of any disturbances, such as unauthorized intruders, security breaches, high temperatures, smoke, water leakages, power outages and more.
Embedded web server displays sensor information and live video from connected cameras
Control PTDZ cameras directly from the web interface
Record digital video to remote servers or internal memory, or send live images to your own website
Connect Digital Cameras, and simultaneously display images up to 640×480 resolution
Receive notifications of anomalous events via email, SMS / MMS, SNMP traps, and many more
Integrates with network management systems via SNMPv1 and Encrypted SNMPv3
Stream video and sensor information directly to your cellphone or PDA
Ability to connect external GPRS / GSM modem, Bluetooth and WiFi USB adapters
Uses Linux operating system for maximum stability and flexibility
Virtual Sensors monitor power, Modbus, network devices, and other SNMP based equipment
Built-in graphing and data logging, internally or to a remote PC
Platform independent; free firmware upgrades and utilities from AKCP
Monitor up to 500 intelligent sensors using expansion modules ( E-Opto 16 and E-Sensor 8 )
Compatible with complete range of AKCP Intelligent Sensors
Full Modbus support : Modbus Master / Slave, Modbus RTU, Modbus over TCP / IP
sensorProbe2+ LCD
The sensorProbe2+ LCD (SP2+LCD) is based on our popular SP2+ device. Equipped with 4 sensor ports, a dry contact I/O it is ideal for server rooms and monitring of individual racks. Connect any AKCP intelligent sensor such as thermal maps, sensor status light, contactless current meters and water leak detection. Mounted on the front, or with a 45° bracket on the top of your rack, the LCD vides a visual display of all sensor status and values.
The SP2+LCD comes PoE built in as standard, the additional 5VDC USB power input can be used as the primary source of power with PoE as backup power.
Environmental Sensor for Data Centers
Temperature Monitoring
Water Leak Detection
Power Monitoring
Temperature Monitoring
High temperatures in your rack are a serious problem, and can cause major downtime. Monitor your room temperature, CRAC units and cabinet temperatures. Thermal map sensors give you a detailed view of the front and rear temperatures as well as the ΔT front to rear temperature differential.
Water Leak Detection
Monitor for water leaks around your chillers, and under raised access flooring. Spot water sensors and rope water sensors are available. Locate type rope water sensors can tell you the precise location of the leak.
Main Line Power
Monitor 1ph or 3ph power. Power Meters can be installed at mainline power intake, as well as at branch level, allowing you to monitor power consumption at multiple locations through its distribution. Monitoring of mainline power is required for PUE calculations.
Access Control
Unlock doors remotely using software control.
Connect a wide variety of electronic lock types.
Expand using AKCP’s Door or Cabinet Expansion Modules.
In / Out EM Card Reader ports granting one or two-way access control.
Connect up to two USB Fingerprint Readers for high-security applications.
Time and Attendance integration with AKCPro Server.
Embedded web server displays sensor information. AKCPro Server (included free of charge) can be used to view connected cameras.
Control PTDZ cameras from AKCPro Server.
Record digital video to remote servers or picture logs to internal memory. Alternatively, send live images to your own website or FTP.
Receive notifications of anomalous events via email, SMS / MMS, SNMP traps, and many more.
Integrates with network management systems via SNMPv1 and Encrypted SNMPv3.
Challenges We Address
​
-
Water leaks or flooding – from pipes, cooling systems, or external sources
-
Air conditioning or HVAC failure – leading to overheating and reduced equipment lifespan.
-
Power and UPS failures – causing unexpected shutdowns and data loss.
-
Electrical fire hazards – due to overloaded circuits or faulty wiring.​
-
Unauthorized access or theft – compromising equipment and data security.
-
Equipment sabotage or rack door left open – resulting in damage or tampering.
-
Gaps in monitoring and responsibility – unclear ownership leading to delayed response
-
Overheating and temperature fluctuations – affecting system stability and reliability.
